Kinect Headtracking with OSC Support

Last Updated on

left: GEM Window, right: head pose estimation by G.Fanellibased on
Real Time Head Pose Estimation from Consumer Depth Cameras by Gabriele Fanelli [1]

======================================
download source and windows/OSX binaries: https://github.com/kronihias/head-pose-estimation

Application that detects head position from a depth image provided by Microsoft Xbox Kinect Sensor in x,y,z and Euler Angles (pitch, yaw, roll) from multiple persons.

–> needs no calibration!!

Application sends data as OSC[2] Message in the format:

/head_pose [User_ID] [x] [y] [z] [pitch] [yaw] [roll]

all arguments are float, angles in degree, User_ID starting at zero.

* can detect angles about +-75° yaw, +-60° pitch and +-50° roll.

Usage:
* #…/head_pose_estimation> ./head_pose_estimation_demo config.txt

example how to not show visualization and use custom ip and port for sending OSC Messages:

./head_pose_estimation_demo config.txt 0 1 192.168.0.1 8000

Default IP/Port: 127.0.0.1:7120

* you can find an example puredata/GEM patch in the folder pd
to visualize the headtracking.

(C) 2011/2012 by Matthias Kronlachner
__________________________________________________________

::INSTALL STANDALONE PROGRAM::
Ready to use Binaries for OSX (64 bit) and Windows (32 bit) are included.

Windows
—————–
Binary is included
Windows version is compiled for Microsoft Kinect SDK!!

* get and install OpenCV from http://sourceforge.net/projects/opencvlibrary/files/opencv-win/2.4.0/
* get and install Microsoft Kinect SDK for Windows http://www.microsoft.com/en-us/kinectforwindows/develop/developer-downloads.aspx

Linux
—————–

* you need cmake, OpenCV, OpenNI, freeglut, and OpenGL libraries
for installing OpenNI follow this instructions: https://github.com/avin2/SensorKinect

* get liblo
http://liblo.sourceforge.net/

* edit demo/CMakeLists.txt and adjust paths

* #…/head_pose_estimation/demo> cmake CMakeLists.txt
* #…/head_pose_estimation/demo> make

* #…/head_pose_estimation> ./head_pose_estimation_demo config.txt

OSX
—————–

* you will need XCode to compile the demo application for OSX

* follow instructions on https://github.com/avin2/SensorKinect
to install OpenNI

* get liblo
http://liblo.sourceforge.net/

* get OpenCV, OpenGL, Glut through macports

* open the XCode Project in demo folder,
adjust path settings for Frameworks and build it.

__________________
:::THINGS TO DO:::

questions: m.kronlachner@gmail.com

  1. [1]http://www.vision.ee.ethz.ch/~gfanelli/head_pose/head_forest.html
  2. [2]Open Sound Control (OSC) is a message based communication protocol for multimedia systems.
